Rear Dump Trailer
Dump Trailer is one of heavy duty trailer. Also known as dumper or engineering vehicle, a dump trailer is equipped with an automatic dumping device. It is composed of automobile chassis, hydraulic lifting mechanism, power take-off device, and cargo compartment. In civil engineering, it often operates along with excavators, loaders, and belt conveyors to form production lines for loading, unloading and transporting earthwork, gravel, and loose materials. Dump trailers have the capability of automatically dumping the material at a certain angle, which significantly saves time and labor, shortens transportation cycle, improves production efficiency, and reduces transportation cost. The carriage can be tilted backward or laterally. | Item | Specification |
| Application | Coal/Mine/Stand/Stone Loading |
| Dump Style | Rear Dump |
| Loading Capacity | 30T-100T |
| Axle | 2/3/4*13/16T FUWA/BPW |
| Length | 11000mm |
| Width | 2500mm |
| Height | 2800mm |
| Cylinder | HYVA (model is according to the length of cargo box) |
| Floor Plate Thickness | 5mm |
| Cargo Thickness | 4mm |
| Cargo Style | Rectanglular/Round |
| Front Axle Lifting | Available |
| | Material Q345/T700 |
| Height: 500mm |
| Upper Plate: 14mm |
| Middle Plate: 8mm |
| Lower Plate: 16mm |
| Tire | 11.00R20/12R222.5*8/12/16 pieces Linglong/Triangle/Double-Coin |
| Rim | 8.0/9.0*8/12/16 pieces, steel/aluminum |
| Suspension | Mechanical/Airbag |
| Leaf Spring | 90mm*13/16mm*10 pieces |
| Landing Gear | 28T two-speed, JOST |
| King Pin | #50(2")/#90(3.5"), JOST/Other Brand |
| Tool Box | Steel/aluminum |
Product Description
Length: 8m, 9m, 10m
Material: carbon steel
Capacity: 30T, 40T, 50T, 60T, 80T, 100T
Number of Axles: 2 axles, 3 axles, 4 axles, 5 axles, 6 axles
King Pin: 2", 3.5", JOST
Tire: 12R22.5, 1100R20, 1200R20
Detailed Photos
Our Advantages
Company Profile
Liangshan Xinrun Trading Co., Ltd. is an integrated enterprise of industry and trade, established in 2023, located in Liangshan County, Jining City, Shandong Province. The company is mainly engaged in the import and export of trailer accessories such as trailers, semi-trailers, dump trailers, axles, chemical equipment, and other goods, automobile sales, retail of automobile parts, second-hand car brokerage, mechanical equipment sales, and metal material sales; Selling construction machinery and retail hardware products; Special equipment sales; Wholesale of hardware products; Motor vehicle repair and maintenance; Tire sales; Sales of pharmaceutical specific equipment. The company values professionalism, integrity, and trustworthiness as its core values. Looking forward to cooperating with you!
Is a comprehensive processing enterprise integrating automobile manufacturing and parts production, scientific research, processing, trade and sales. The company is located in Liangshan Industrial Park. The company's main products include low flatbed, tailboard, van, storage rack semi-trailer, tanker, dump truck, and special vehicles, etc., and undertakes the modification and design business of vehicles and special vehicles. We are proficient in manufacturing and dedicated to research and development. We have the domestic manufacturing equipment and production technology, with a complete and scientific quality management system. We are always committed to providing customers with high-quality road transportation products. The company integrates product design, scientific research and development, production and sales.
FAQ
Q:Which payment terms can you accept?
A:Payment term is negotiable and there will be favorable payment terms for long-term customers. Tt, l/cd/p. Depending on the cooperation time country and contract walue.
Q:Whether you could make our brand on your products?
A:Yes. We can print your logo on both the products and the packages if you can meet our moq.
Q:Whether you could make your products by our color?
A:Yes, the color of products can be customized if you can meet our moq.
Q:Which countries do you export to?
A:Asia: India, thailand, burma, vietnam, bangladesh, kazakhstan, turkmenistan, etc. Middleeast: Saudi arabia, iran, uae. Jordan, oman, syria, pakistan, qatar, etc. Europe: Russia, ukraine.Belarus, bulgaria, etc.Africa: South africa, kenya, congo, ethiopia, nigeria, ghana,algeria, senegal,tunisia, etc.
Q:Why choose us?
A1.We offer a diverse range of trailer types to cater to various customer needs. From flatbed trailers to enclosed trailers and specialized trailers, we have a comprehensive selection to accommodate different cargo requirements.
A2.While delivering top-quality trailers, we strive to maintain competitive pricing in the market.
A3.We have high-quality products, we pay attention to the quality and durability of trailers, using high-quality materials and advanced manufacturing processes to ensure that the trailers we produce have excellent quality standards and long life.
